Specifications:
Brand: ZLINE Kitchen and Bath
Dimensions:
Airflow (Q/L/M/H): 120/240/320/400
Lighting: 2 Directional LED Lights (3-Watt)
Noise Level: 20/29/34/41 (Decibels)
Voltage: 110V/60HZ
Motor: High Performance 400 CFM/4-Speed Motor
Mount Type: Wall Mounted
Speeds: 4 Speeds
Control Type: Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Filters: Stainless Steel Baffle Filters (Dishwasher Safe)
Material: 7-Layer Baked Copper Finish
Warranty: 3 Year Parts Warranty
Features:
Dimensions:
- 8KBC-30: 30" W x 17.7" D x 10.5" H
- 8KBC-36: 36" W x 19.7" D x 10.5" H
- 8KBC-42: 42" W x 19.7" D x 10.5" H
- 8KBC-48: 48" W x 19.7" D x 10.5" H
-
9.2" W x 8.0" D x 36" H - Fits ceilings up to 9.5 ft. Must custom cut.
- Includes Crown Molding. Vented Crown Molding available for Ductless solution.
Airflow (Q/L/M/H): 120/240/320/400
Lighting: 2 Directional LED Lights (3-Watt)
Noise Level: 20/29/34/41 (Decibels)
Voltage: 110V/60HZ
Motor: High Performance 400 CFM/4-Speed Motor
Mount Type: Wall Mounted
Speeds: 4 Speeds
Control Type: Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Filters: Stainless Steel Baffle Filters (Dishwasher Safe)
Material: 7-Layer Baked Copper Finish
Warranty: 3 Year Parts Warranty
Features:
- Model No. 8KBC-30, 8KBC-36, 8KBC-42, 8KBC-48
- 8KBC-30: 814118022416
- 8KBC-36: 814118022423
- 8KBC-42: 814118022430
- 8KBC-48: 814118022447
| Name | Definition | Category | Are We Compliant? |
| CSA General | Testing and Certification Body | Electric | Yes |
| ETL Intertek | Testing and Certification Body | Safety | Yes |
| CSA 22.2. No. 61-08. | CSA Standard Household Cooking Ranges | Electric | Yes |
| UL Listed | Safety | Yes | |
| CA Prop 65 (CEC). | Safe Drinking Water and Toxic Enforcement Act | Water | Yes |
