Specifications:
Brand: ZLINE Kitchen and Bath
Dimensions:
- 8667B-30: 30" W x 24" D x 16.375" H
- 8667B-36: 36" W x 24" D x 16.375" H
- 8667B-48: 48" W x 24" D x 16.375" H
Chimney:
-
13.5" W x 11.75" D x 36" H - Fits ceilings up to 10 ft. Must custom cut.
- Includes Crown Molding.
- Chimney Extension available for ceilings up to 12.5 ft.
Venting Size:
- 8667B-30: 6" Outlet (Transition piece to round ducting included)
- 8667B-36: 8" Outlet (Transition piece to round ducting included)
- 8667B-48: 8" Outlet (Transition piece to round ducting included)
Airflow (Q/L/M/H):
- 8667B-30: 120/240/320/400
- 8667B-36: 280/460/670/700
- 8667B-48: 280/460/670/700
Lighting:
- Directional LED Lights (3-Watt)
Noise Level:
- 8667B-30: 20/29/34/41 (Decibels)
- 8667B-36: 30/41/49/52 (Decibles)
- 8667B-48: 30/41/49/52 (Decibles)
Voltage: 110V/60HZ
Motor:
- 8667B-30: High Performance 400 CFM/4-Speed Motor
- 8667B-36: High Performance 700 CFM/4-Speed Motor
- 8667B-48: High Performance 700 CFM/4-Speed Motor
Mount Type: Wall Mounted
Speeds: 4 Speeds
Material: 7-Layer Copper Finish
Filters: Stainless Steel Baffle Filters (Dishwasher Safe)
Control Type: Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Warranty: 3 Year Parts Warranty
UPC:
- 8667B-30: 814118022201
- 8667B-36: 814118020214
- 8667B-48: 814118020238
Certifications: ETL Listed
| Name | Definition | Category | Are We Compliant? |
| CSA General | Testing and Certification Body | Electric | Yes |
| ETL Intertek | Testing and Certification Body | Safety | Yes |
| CSA 22.2. No. 61-08. | CSA Standard Household Cooking Ranges | Electric | Yes |
| UL Listed | Safety | Yes | |
| CA Prop 65 (CEC). | Safe Drinking Water and Toxic Enforcement Act | Water | Yes |
