Choose a size: |
|
Dimensions
• 681W-RD-30: 30 in. W x 22 in. D x 8 in. H
• 681W-RD-36: 36 in. W x 22 in. D x 8 in. H
• 681W-RD-48: 48 in. W x 22 in. D x 8 in. H
• 681W-RS-30: 30 in. W x 22 in. D x 8 in. H
• 681W-RS-36: 36 in. W x 22 in. D x 8 in. H
• 681W-RS-48: 48 in. W x 22 in. D x 8 in. H
Chimney: 13.375" W X 11.75" D x 16" H (x2) (Telescoping)
Venting Size: 8" Outlet (Transition piece with backdraft damper to round ducting included)
Charcoal Filters (not included) available for ductless/recirculating option.
Airflow (Q/L/M/H):
- 681W-RD: 280/460/670/700
- 681W-RS: 120/240/320/400
Lighting: LED Lights
Noise Level:
- 681W-RD: 30/41/49/52 (Decibels)
- 681W-RS: 20/29/34/41 (Decibels)
Voltage: 110V/60HZ
Motor: High Performance 4-Speed Motor
Mount Type: Wall Mounted
Speeds: 4 Speeds
Control Type: Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Material: Solid-piece Butcher Block with Walnut Finish
Warranty: 3 Year Parts Warranty
| Name | Definition | Category | Are We Compliant? |
| CSA General | Testing and Certification Body | Electric | Yes |
| ETL Intertek | Testing and Certification Body | Safety | Yes |
| CSA 22.2. No. 61-08. | CSA Standard Household Cooking Ranges | Electric | Yes |
| UL Listed | Safety | Yes | |
| CA Prop 65 (CEC). | Safe Drinking Water and Toxic Enforcement Act | Water | Yes |
