Dimensions
• 597-30 Dimension: 30" W x 20.25" D x 14" H
• 597-36 Dimension: 36" W x 20.25" D x 14" H
• 597-42 Dimension: 42" W x 20.25" D x 14" H
• 597-48 Dimension: 48" W x 20.25" D x 14" H
• 597-54 Dimension: 54" W x 20.25" D x 14" H
• 597-60 Dimension: 60" W x 20.25" D x 14" H
Chimney: 11.75" W x 10.75" D x 16" H (x2) (Telescoping)
Chimney Short Kit and Extension(s) Available:
Short Kit (2-12") ~7-8 ft. Ceilings
1 PC Extension (1-36" + 1-16") ~9-10 ft. Ceilings
2 PC Extension (2-36") ~10-12 ft. Ceilings
Venting Size: 6" Outlet (Transition piece to round ducting included)
Charcoal Filters (not included) available for ductless/recirculating option.
Airflow (Q/L/M/H): 260/340/420/500
Lighting: LED Lights
Noise Level: 20/29/34/41 (Decibels)
Voltage: 110V/60HZ
Motor: High Performance 500 CFM/4-Speed Motor
Mount Type: Wall Mounted
Speeds: 4 Speeds
Control Type: Speed/Timer Panel with LCD (3 Minute AutoTimer with Delayed Shutoff)
Material: 21g #430 Stainless Steel
Warranty: 3 Year Parts Warranty
| Name | Definition | Category | Are We Compliant? |
| CSA General | Testing and Certification Body | Electric | Yes |
| ETL Intertek | Testing and Certification Body | Safety | Yes |
| CSA 22.2. No. 61-08. | CSA Standard Household Cooking Ranges | Electric | Yes |
| UL Listed | Safety | Yes | |
| CA Prop 65 (CEC). | Safe Drinking Water and Toxic Enforcement Act | Water | Yes |
